800x480 HD IPS Display 4.3" - LVDS Interface Enabled, High-Definition Screen for Industrial Use

IPS LCD size: 4.3 inch
Part Number:RXL043022-F
Resolution: 800X480
LCD Dimensions: 105.4mm*67.15mm*2.91mm
LCD viewing area: 95.04mm*53.86mm
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • RXL043022-F

  • Reshine Display

An IPS (In-Plane Switching) TFT (Thin-Film Transistor) LCD (Liquid Crystal Display) is a type of display technology commonly used in electronic devices such as smartphones, tablets, computer monitors, and televisions. It is known for its superior color reproduction, wide viewing angles, and high-quality visual performance.


IPS TFT LCD displays have become increasingly popular due to their excellent color reproduction, wide viewing angles, and overall visual quality. They are commonly used in devices where color accuracy and viewing experience are crucial, such as Medical display,Automotive display,Monitors,Industrial control,Transportation and Point-of Sale systems.




Hot tags:4.3 ips tft lcd display, 800x480 4.3 tft lcd, 4.3 inch capacitive touch screen, 4.3 inch tft lcd module display touch screen, tft lcd screen, tft lcd monitor mobile, capacitive multi touch screen, resistive versus capacitive touch screen, 1.44 tft lcd module, 10 inch tft lcd display, china, customized, suppliers, factory, manufacturers.

Product Name:4.3 Inch Industrial IPS LCD Display (Part Number: RXL043022-F)

Resolution:800x480 Pixels (WVGA), Clear Visual Experience

Physical Specifications:

Overall Dimensions: 105.4mm × 67.15mm × 2.91mm (Slim Design)

Active Viewing Area: 95.04mm × 53.86mm

Interface Type:4-Lane LVDS Interface, Stable Signal Transmission

Brightness:600 Nits High Brightness, Suitable for Outdoor/Industrial Scenarios

Core Parameters:

Driver IC: ST7262

Display Mode: Normal Black

Display Color: 16.7 Million Colors (True Color)

Polarizer Mode: Transmissive

Viewing Angle: Full View (IPS Technology,360° Clear Viewing)

Temperature Range:

Operating Temp: -20°C ~ +70°C (Wide Temperature Adaptation)

Storage Temp: -30°C ~ +80°C

Lead Time: Samples In Stock (Ready to Ship); Mass Production: 3-4 Weeks

Customization Support :Yes (Tailored Solutions Available)
