Replacing a laptop screen can seem like a daunting task, especially if you own a specific model such as the HP laptop equipped with the 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001. However, with the right tools, careful steps, and some patience, you can successfully replace your damaged or malfunctioning screen yourself. This comprehensive guide will walk you through the entire process, from identifying the correct replacement part to safely installing the new screen and testing it.
Before diving into the replacement steps, it's important to understand what the 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001 entails. This is a full display assembly designed for HP laptops, featuring:
- A 15.6-inch diagonal screen size
- BrightView technology for enhanced brightness and clarity
- Full HD resolution (1920 x 1080 pixels)
- LED backlighting for energy efficiency and vivid colors
- Touchscreen capability, integrating digitizer and glass
- Includes webcam/microphone modules and wireless antenna cables integrated into the assembly
This assembly is specifically designed for certain HP laptop models and is identified by the part number 720550-001. It is recommended to replace the entire assembly rather than just the glass or digitizer to ensure proper functionality and durability.
To replace your HP laptop screen with the 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001, gather the following tools and materials:
- A replacement screen assembly (part number 720550-001)
- Small Phillips screwdriver (PM2.0 or PM2.5 recommended)
- Plastic pry tools or guitar picks for bezel removal
- Tweezers for handling small connectors and adhesive strips
- Double-sided adhesive strips designed for laptop screens
- Anti-static wrist strap or grounding method to prevent static damage
- Clean, flat workspace with good lighting
Having these tools ready will make the process smoother and reduce the risk of damaging your laptop components.
- Power off your laptop completely and disconnect it from any power source.
- If your model allows, remove the battery to avoid any electrical hazards.
- Ground yourself by touching a metal surface or using an anti-static wrist strap to prevent electrostatic discharge damage.
- Locate any screws securing the bezel, often hidden under rubber screw covers or stickers. Remove these screws carefully.
- Use a plastic pry tool or guitar pick to gently pry the bezel away from the screen frame, starting at a corner and working your way around. The bezel is held by plastic clips and sometimes adhesive, so patience is key.
- Carefully detach the bezel without applying excessive force to avoid cracking it.
- With the bezel removed, locate the screws securing the screen assembly to the laptop's display enclosure. Typically, there are two to four screws on the sides or corners. Remove these screws.
- Gently tilt the screen forward to access the video cable on the back.
- Peel off any tape securing the video cable connector.
- Unlock the connector latch if present (usually a small flip or slide mechanism) and carefully disconnect the video cable.
- Also disconnect any touchscreen digitizer cables if applicable.
- Remove the old screen assembly completely from the laptop.
- Unpack the new 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001 carefully, avoiding touching the display surface.
- Compare it with the old screen to ensure it is the exact match.
- Connect the video cable and touchscreen digitizer cables securely to the new screen.
- Place the new screen assembly into the display enclosure, aligning it properly.
- Reinstall the screws to secure the screen in place.
- If adhesive strips are used, clean the surfaces with alcohol wipes and apply new double-sided adhesive strips to hold the screen firmly.
- Before reattaching the bezel, reconnect the battery and power on the laptop.
- Check for display clarity, color accuracy, and touchscreen responsiveness.
- Look for any dead pixels or flickering.
- If the screen works perfectly, power off the laptop again.
- Carefully snap the bezel back onto the screen frame, ensuring all clips are securely in place.
- Replace the screws and rubber screw covers if applicable.
- Reinstall the battery if it was removed.
- Power on the laptop one final time to confirm everything is working properly.
Replacing the 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001 is not only about the mechanical steps but also about understanding the nuances that can affect the success of your repair.
Because this assembly includes a touchscreen, extra care must be taken with the digitizer cable. Unlike traditional non-touch screens, the touchscreen digitizer is a sensitive component that can easily be damaged if mishandled. Avoid pulling on cables or connectors forcefully and ensure the connectors are fully seated before powering on the device.
Once the new 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001 is installed, it may be necessary to calibrate the touchscreen for optimal accuracy. Most modern operating systems have built-in calibration tools accessible through the control panel or settings menu. Running a calibration ensures that touch inputs correspond precisely to the screen locations.
Performing the replacement in a clean, dust-free environment is crucial. Dust or debris trapped between the screen and bezel can cause display imperfections or interfere with touchscreen sensitivity. Additionally, avoid static-prone environments to minimize the risk of electrostatic discharge damaging sensitive components.
If the bezel is difficult to remove, avoid using excessive force which can crack the plastic. Instead, gently work your plastic pry tool around the edges, applying slow, steady pressure. Warm the bezel slightly with a hairdryer to soften any adhesive if necessary.
If the touchscreen is unresponsive after installation, double-check all cable connections. Sometimes connectors may appear connected but are not fully seated. Disconnect and reconnect the digitizer cable carefully. Also, verify that the replacement screen is an exact match for your laptop model.
New screens can occasionally have dead pixels or other defects. If you notice such issues immediately after installation, contact the supplier for a replacement. Testing the screen before fully reassembling the laptop can save you time and effort.
- Take photos during disassembly to help with reassembly.
- Keep track of all screws and their locations.
- Handle cables gently to avoid tearing or damaging connectors.
- Use proper adhesive strips designed for laptop screens to avoid loose fitting.
- If unsure about any step, consult the HP service manual specific to your laptop model or seek professional assistance.
- Use an anti-static wrist strap to prevent electrostatic damage.
- Work slowly and patiently to avoid accidental damage.
Replacing your HP laptop screen with the 15.6 inch BrightView FHD LED Touchscreen Display Assembly 720550-001 is a manageable DIY project with the right preparation and tools. This replacement not only restores your laptop's display quality but also extends its usable life, saving you the cost of a new device. By following careful step-by-step instructions, ensuring compatibility of parts, and testing thoroughly, you can confidently perform this repair at home. Remember, patience and attention to detail are key to a successful screen replacement. Proper handling of the touchscreen components and calibration after installation will ensure your laptop functions like new.
Check your laptop's model number and cross-reference it with the part number 720550-001 in the HP parts catalog or service manual. This assembly is designed for specific HP models that support a 15.6-inch BrightView FHD touchscreen. Using the exact part number ensures compatibility and functionality.
While it is technically possible to replace only the glass or digitizer, it is often more complicated and risky. The full assembly replacement is recommended because it includes the screen panel, digitizer, and housing, ensuring better durability and easier installation.
Essential tools include a small Phillips screwdriver, plastic pry tools or guitar picks for bezel removal, tweezers for cable handling, and double-sided adhesive strips. An anti-static wrist strap is also recommended to prevent electrostatic damage.
For someone with basic technical skills, the replacement can take between 30 minutes to an hour. First-timers may take longer due to careful disassembly and reassembly.
Double-check all cable connections to ensure they are secure and properly seated. Verify that the screen is compatible with your laptop model. If problems persist, consider consulting a professional technician or contacting HP support for further assistance.
